Description
Three Newly Added Functions


Bluetooth Remote Control

12v/24v Auto Switch
Core of Independent Power System-Inverter

The inverter, the core of an off-grid power system, supplies various power for some of your important appliances.
With batteries and the inverter, you can carry utility power with yourself to anywhere you want to go.
The added solar panel gives you another cost-saving and green energy source.
And it also gives you a real independent power supply.
Where there is the sun, there is the power.
Technical Parameters
Technical Parameters
Model | P-800W-12V | P-800W-24V | P-800W-48V |
Output Power | 800W | ||
Peak Power | 1600W | ||
DC Input Voltage Range | DC12V(9.5V-15.5V) | DC24V(19V-31V) | DC48V(38V-62V) |
AC Output Voltage (Single Choice) | 100V/110V/120V/220V/230V/240V | ||
Unload Current | ≤0.6A | ≤0.3A | ≤0.2A |
Output Frequency | (50Hz±2Hz) or( 60Hz±2Hz) | ||
Output Waveform | Pure sine wave | ||
Display | / | ||
USB Output Votlage / Current | 5V 2A (Support QC3.0 fast charge up to 18W) | ||
Max. Output Efficiency | 88% | 90% | 92% |
Low Voltage Protection | Alarm “Bi” with 2s interval +red and green lights flashing alternately / restart automatically when voltage recover | ||
Over Voltage Protection | Alarm “BiBi” with 1s interval +red and green lights flashing alternately / restart automatically when voltage recover | ||
Over Load Protection | Alarm “Bi” continously +red light flashing / restart automatically when load power recover; If it is closed after twice recover, it need restart manually. | ||
Over Temp Protection | Alarm “BiBiBi” with 1s interval +red and green lights flashing alternately / restart when temp recover | ||
Short Circuit Protection | yes | ||
DC Reverse Connection Protection | Fuse burnt | ||
Low Voltage Alarm Range | 10.5v±0.5v | 21v±0.5v | 42v±0.5v |
Low Voltage Protection Range | 9.5v±0.5v | 19v±0.5v | 38v±0.5v |
Low Voltage Recover Range | 12v±0.5v | 23v±0.5v | 46v±0.5v |
Over Voltage Protection Range | 15.5v±0.5v | 31v±0.5v | 62v±0.5v |
Over Voltage Recover Range | 14v±0.5v | 28v±0.5v | 56v±0.5v |
Working Temperature | -10℃~50℃ | ||
Cooling Method | Fan cooling (Temperature control) | ||
Note: The tech updates constantly. These datas are used for reference only. Please refer to our real product. |
